Transmission frequency: 120GHz ~ 130GHz, FM scanning frequency width 10GHz

Measuring range: 0.1m-50m/100m/ 150m

Measurement resolution: 0.008m

Maximum allowable error: ±0.7mm

Beam angle: 0.7° (with lens radome)

Dielectric constant range: 1.0~100, medium viscosity <1000cp

Power supply voltage: 24VDC, two-wire system

Communication method: HART/MODBUS

Signal output: 4 ~ 20mA (with HART/MODBU)

Control output: 1 channel, 24VDC, 5A relay; configurable alarm range control

Fault output: 4mA, 22mA and 20.5mA (configurable)

On-site operation/programming: 4 buttons, configurable PC setting software/Wi-Fi/BT+mobile APP application/SIMBA tank side meter

Process temperature/humidity: -60～200℃/≤95%RH; -60～1000℃ (with antenna cooling pipe/quartz isolation flange)

Shell material: aluminum alloy

Antenna type: lens antenna, PTFE/PEEK/PE, can be equipped with lens antenna shield/anti-corrosion antenna/antenna heat pipe/quartz isolation flange

Process pressure: -1～5MPa; -1～32MPa (with quartz isolation flange)

Product size: 253mm x 97mm x 97mm (excluding mounting parts)

Cable entry: M20x1.5

Recommended cable: AWG18 or 0.75m㎡

Protection class: IP67

Explosion-proof mark: Ex ia/d IIC T4～T6 Ga/Gb

Installation method: M56x2 thread / or DN50 flange installation

Net weight/gross weight: 4.00Kg / 3.51Kg

Packing box size: L x W x H 435mm x 275mm x 275mm
